Rigorously tested by EFBE. Passed TRI-TEST® GR. Certified for freeride and downhill mountain bikes
Machined from solid 6061 T6 aluminum
SPECIFICATIONS
35mm clamp diameter
35mm length (177g)
40mm length (197g)
Zero rise
58mm width
38mm stack height
M6 x 1.0 x 18mm / 20mm stainless steel bolts
INTENDED USE
All MTN / Enduro
Downhill / Freeride
Dirt Jump / Slopestyle
Skatepark / Street
RECOMMENDATIONS
Handlebar clamps to be tightened with equal gaps on top and bottom. All stems have MAX Torque specs etched onto the stem body. Note that MAX torque specs are just that, a maximum rating. For most purposes, 5-6nm should be adequate.
